Epoxy Pultruded Product Specifications

Properties Unit Standard Specified value Obtained value
Water absorption % ASTM-D 570-81 0.2 MAX. 0.007
Sp. Gravity at 270 c   ASTM-D 792-91 2 2 2.2
Sp. Gravity at 270 c Kg/ cm2 ASTM-D 638-91 7500 10715
Impact strength KJ/m2. ASTM-D 256-2003 400 min >408
Arc resistance,sec   ASTM-D-495-99 186
Compressive strength(axial) Kg/cm2. ASTM-D 695-91 4000 6248
Flexural strength Kg/cm2 ASTM-D 349-78 5000 9550
Comparative tracking index CTI VOLTS IES 60112-2003 600 min >600
Di-electric strength proof axial KV / mm ASTM-D 149-97a 50 KV/25 min. 66
Di-electric strength proof radial KV/mm ASTM-D 149-97a 10 KV / MM 15
Insulation resistance ohms ASTM-D 257-92 1 x 1010 1.9 x 1015
Martens heat distortion temperature 0C DIN 53462 1987 MIN 200 >210
Splitting resistance,n   IS10192-82,
Appendix D
4000 5346
Glass content % BS-4994 1987 80 5 82

FRP Fastners

Properties M10 M12 M16 M20
Ultimate thread shear using Fiber glass nut (KG) 2900 3886 4972 14072
Specific Gravity 2.0
+ 0.2
2.0
+ 0.2
2.0
+ 0.2
2.0
+ 0.2
Tensile Strength (MPA) 750
(Min)
750
(Min)
750
(Min)
750
(Min)
Cross Breaking Strength (MPA) 900
(Min)
900
(Min)
900
(Min)
900
(Min)
Compressive strength (Kj/m 2) 100
(Min)
100
(Min)
100
(Min)
100
(Min)
Water Absorption
(% By Weight)
0.1 % 0.1 % 0.1 % 0.1 %
Electrical Strength,
Min (Proof Voltage at
90 0C in oil) Radial (KG/mm) Axial
(Kv / 25mm)
10
(Min)
50
(Min)
10
(Min)
50
(Min)
10
(Min)
50
(Min)
10
(Min)
50
(Min)
Insulation Resistance (OHMS) 10 10
(Min)
10 10
(Min)
10 10
(Min)
10 10
(Min)
Martens Heat Distortion Temp (0C) 200
(Min)
200
(Min)
200
(Min)
200
(Min)
